Bobcat L28 Small Articulated Loader

  • Bobcat L28 Small Articulated Loader
  • Bobcat L28 Small Articulated Loader
  • Bobcat L28 Small Articulated Loader
  • Bobcat L28 Small Articulated Loader
  • Bobcat L28 Small Articulated Loader
  • Bobcat L28 Small Articulated Loader
  • Video Button Maxresdefault
  • Video Button Hqdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

Small Articulated Loader

The L28 Bobcat® small articulated loader delivers big performance and heavy lifting in a small package.

  • Easily works inside fenced-in landscapes, pens, backyards and more.
  • Impressive lifting capacity and telescoping lift arm
  • Tight-turning articulation joint
  • The Bobcat® L28 small articulated loader is a compact machine that easily works inside fenced-in landscapes, pens, backyards and more.
  • Offers impressive lifting capacity and a telescoping lift arm for added reach.
  • Its tight-turning articulation joint improves maneuverability while the nimble design offers a light footprint for minimal damage to turf.



Specifications
Model
L28
Category Name
Skid Steer
Year
2025
Sale Type
New
Manufacturer
Bobcat
l28 key specifications
Horsepower
24.8 hp
Operating Weight
4195 lbs
Auxiliary Std Flow
11.4 gpm
Width (over Tires)
46.5 in
Rated Operating Capacity (ISO) (Straight)
1534 lbs
Rated Operating Capacity (ISO) (Articulated)
1222 lbs
engine
Horsepower
24.8 hp
Fuel Consumption
1.1 gph
Turbocharged Engine
performance
Travel Speed
8.3 mph
Operating Weight
4195 lbs
Tipping Load - Straight
3068 lbs
Tipping Load - Articulated
2444 lbs
ROC With Counterweight Option - Straight
1952 lbs
Rated Operating Capacity (ISO) (Straight)
1534 lbs
ROC With Counterweight Option - Articulated
1475 lbs
Rated Operating Capacity (ISO) (Articulated)
1222 lbs
capacities
Fuel Tank
9.6 gal
hydraulic system
Auxiliary Std Flow
11.4 gpm
System Relief @ Quick Couplers
2900 psi
dimensions
Tire Size
23X10.5-12, 8 PLY
Wheelbase
47.2 in
Wheel Tread
36.4 in
Rollback Angle
32 deg
Ground Clearance
5.5 in
Articulation Angle
43 deg
Width (over Tires)
46.5 in
Width (with Bucket)
50 in
Inside Turning Radius
78.2 in
Outside Turning Radius
100.9 in
Reach @ Maximum Height
30.9 in
Length Without Attachment
93.2 in
Dump Angle @ Maximum Height
40 deg
Length With Standard Bucket
122.4 in
Height To Bucket Hinge Pin - Extended
104.4 in
drive system
Main Drive
Hydrostatic drive with 4 individual drive motors
